Size

Outside Dia

Socket Type

Structure Diameter

D1

D2

d1

d2

I1

d3

d4

I2

L

H

d

d0

3/4" × 3/4" × 1/2"

37

32

26.87

26.57

25.4

21.54

21.23

22.22

88

38.5

22

16.5

1" × 1" × 1/2"

44

30

33.65

33.27

28.58

21.54

21.23

22.22

97

41

28

16.5

1" × 1" × 3/4"

46

32

33.65

33.27

28.58

26.87

26.57

25.4

97

44

28

22

1" × 1" × 2"

44

73

33.65

33.27

28.58

60.63

60.17

38.1

97

65

28

28

1-1/4" × 1-1/4" × 1/2"

57

32

42.42

42.04

31.75

21.54

21.23

22.2

116

44.5

35

16.5

1-1/4" × 1-1/4" × 3/4"

57

37

42.42

42.04

31.75

26.87

26.57

25.4

116

48

35

22

1-1/4" × 1-1/4" × 1"

57

46

42.42

42.04

31.75

33.65

33.27

28.58

116

52

35

28

1-1/2" × 1-1/2" × 1/2"

62

32

48.56

48.11

34.93

21.54

21.23

22.22

128.5

48.5

43

16.5

1-1/2" × 1-1/2" × 3/4"

62

37

48.56

48.11

34.93

26.87

26.57

25.4

128.5

52

43

22

1-1/2" × 1-1/2" × 1"

62

48

48.56

48.11

34.93

33.65

33.27

28.58

128.5

55.5

43

28

1-1/2" × 1-1/2" × 1-1/4"

62

56

48.56

48.11

34.93

42.42

42.04

31.75

128.5

60

43

35

2" × 2" × 1/2"

76

32.5

60.63

60.17

38.1

21.54

21.23

22.22

146

54

54

16.5

2" × 2" × 3/4"

76

37

60.63

60.17

38.1

26.87

26.57

25.4

146

57.5

54

22

2" × 2" × 1"

76

46

60.63

60.17

38.1

33.65

33.27

28.58

146

60.5

54

28

2" × 2" × 1-1/4"

76

56

60.63

60.17

38.1

42.42

42.04

31.75

146

65

54

35

2" × 2" × 1-1/2"

76

62

60.63

60.17

38.1

48.56

48.11

34.93

146

69

54

43

2-1/2" × 2-1/2" × 1"

91

46

73.38

72.85

44.45

33.65

33.27

28.58

171

67.5

65

28

2-1/2" × 2-1/2" × 1-1/4"

91

54

73.38

72.85

44.45

42.42

42.04

31.75

171

72

65

35

2-1/2" × 2-1/2" × 1-1/2"

91

62

73.38

72.85

44.45

48.56

48.11

34.93

171

75.5

65

43

2-1/2" × 2-1/2" × 2"

91

75

73.38

72.85

44.45

60.63

60.17

38.1

171

79

65

54

3" × 3" × 1"

107

46

89.31

88.7

47.63

33.65

33.27

28.58

196

77.5

80

28

3" × 3" × 1-1/4"

107

56

89.31

88.7

47.63

42.42

42.04

31.75

196

77.5

80

35

3" × 3" × 1-1/2"

107

62

89.31

88.7

47.63

48.56

48.11

34.93

196

82

80

43

3" × 3" × 2"

107

75

89.31

88.7

47.63

60.63

60.17

38.1

196

86.5

80

54

3" × 3" × 2-1/2"

107

91

89.31

88.7

47.63

73.38

72.85

44.45

196

95

80

65

4" × 4" × 1"

133

46

114.76

114.07

57.15

33.65

33.27

28.58

237.5

89.5

100

28

4" × 4" × 1-1/4"

133

57

114.76

114.07

60.15

42.42

42.04

31.75

237.5

90.5

100

38

4" × 4" × 1-1/2"

133

64

114.76

114.07

57.15

48.56

48.11

34.93

237.5

97

100

43

4" × 4" × 2"

133

75

114.76

114.07

57.15

60.63

60.17

38.1

237.5

96

100

54

4" × 4" × 2-1/2"

133

91

114.76

114.07

57.15

73.38

72.85

44.45

237.5

104

100

65

4" × 4" × 3"

133

107

114.76

114.07

57.15

89.31

88.7

47.63

237.5

110

100

80

5" × 5" × 2"

163

75

141.81

141.04

66.68

60.63

60.17

38.1

237.5

114.5

132

54

6" × 6" × 1"

191

45

168.83

168

76.2

33.65

33.27

28.58

298

115

150

29

6" × 6" × 1-1/4"

191

54

168.83

168

76.2

42.42

42.04

31.75

336.5

120

150

38

6" × 6" × 1-1/2"

191

60.5

168.83

168

76.2

48.56

48.11

34.93

336.5

123

150

44

6" × 6" × 2"

191

73

168.83

168

76.2

60.63

60.17

38.1

336.5

125

150

54

6" × 6" × 2-1/2"

191

89

168.83

168

79.2

73.88

72.85

44.45

336.5

130

150

65

6" × 6" × 3"

191

105

168.83

168

76.2

89.31

88.7

47.63

336.5

135

150

80

6" × 6" × 4"

191

132

168.83

168

76.2

114.76

114.07

57.15

336.5

145

150

100

8" × 8" × 2"

246

75

219.84

218.69

101.6

60.63

60.17

38.1

439

151

200

54

8" × 8" × 3"

246

105

219.84

218.69

101.6

89.31

88.7

47.63

439

160

200

80

8" × 8" × 4"

246

132

219.84

218.69

101.6

114.76

114.07

57.15

439

170

200

100

8" × 8" × 6"

246

191

219.84

218.69

101.6

168.83

168

76.2

439

194

200

150

10" × 10" × 2"

307

74

273.81

272.67

127

60.63

60.17

38.1

560

185

265

54

10" × 10" × 3"

307

107

273.81

272.67

127

89.31

88.7

47.63

560

194

265

80

10" × 10" × 4"

307

134

273.81

272.67

127

114.76

114.07

57.15

560

205

265

100

10" × 10" × 6"

307

193

273.81

272.67

127

168.83

168

76.2

560

225

265

160

10" × 10" × 8"

307

248

273.81

272.67

127

219.84

218.69

101.6

560

250

265

210

12" × 12" × 2"

364

74

324.61

323.47

152.4

60.63

60.17

38.1

660

215

315

54

12" × 12" × 3"

364

108

324.61

323.47

152.4

89.31

88.7

47.63

660

225

315

80

12" × 12" × 4"

364

136

324.61

323.47

152.4

114.76

114.07

57.15

660

235

315

100

12" × 12" × 6"

364

195

324.61

323.47

152.4

168.83

168

76.2

660

255

315

160

12" × 12" × 8"

364

248

324.61

323.47

152.4

219.84

218.69

101.6

660

280

315

210

12" × 12" × 10"

364

308

324.61

323.47

152.4

273.81

272.67

127

660

298

315

265

14" × 14" × 4"

396.5

133

356.49

355.22

205

114.76

114.07

57.15

856.5

290

346

100

14" × 14" × 6"

396.5

192

356.49

355.22

*205

168.83

168

76.2

856.5

310

346

144

14" × 14" × 8"

396.5

246

356.49

355.22

*205

219.84

218.69

101.6

856.5

339

346

200

14" × 14" × 10"

396.5

307

356.49

355.22

*205

273.81

272.67

127

856.5

365

346

259

14" × 14" × 12"

396.5

364

356.49

355.22

*205

324.61

323.47

152.4

856.5

390

346

308
